Lovibond PFXi-195/4 + RCMSi Pack Colour Measurement for Beers, Malts & Caramels

Sale price£6,847.07

Colour Measurement for Beers, Malts & Caramels

  • Integrated RCMSi Technology for Remote Calibration*
  • Automatic and Non-subjective Colour Measurement
  • Consistent Data Compliant with International Standards
  • Very Rugged, Chemically Resistant, Steel Construction

The PFXi series of spectrophotometric colorimeters introduces a unique concept in liquid colour control: RCMSi technology. You can benefit from the capability for remote calibration and servicing via the internet - saving the cost and time associated with servicing and guaranteeing compliance with standards.

The PFXi range is supplied with a full range of colour scales for specific markets including, but not limited to, Petroleum, Edible Oils, Pharmaceuticals, Brewing and Honey. Users can upgrade scales remotely at any time.

Note: When dealing with materials such as fats and waxes whose temperature needs to be maintained at a constant temperature +10°C above the "Cloud Point" of the material, the PFXi-880, -950 & -995 series should be considered. These are available with an additional critical feature, an optional integrated heater unit.

 *replaced by a second Filter in specific regions

Technical Data:

Applicable Standard ASBC
ASTM E308
EBC Analytika
Colour Type Transparent
Measuring Principle 9 interference filters
Repeatability ±0.0004 (CIE xy Chromaticity) on measurements of de-ionised water
Detector blue enhanced photodiode
Display 240 x 128, back-lit graphic display, (white on blue)
Interfaces USB
RS 232
Ethernet
Path Length 0.1 - 50 mm
Measuring Geometrics 0° - 180° Transmission
Internal Storage 100,000+ Messungen
Measurement Time less than 30 seconds
Sample Chamber max 50mm cells
Keypad 23 key tactile membrane keypad; washable polyester with audible feedback
Instrument Housing Fabricated steel with tough, textured paint finish
Spectral Range 420 - 710 nm
Bandwidth 10 nm
Baseline Calibration Single key press; fully automated
Illuminants CIE Illuminant A
CIE Illuminant B
CIE Illuminant C
CIE Illuminant D65
Portability Benchtop
Observer 2°, 10°
Compliance CE
RoHS
WEEE
Languages User Interface English, German, French, Italian, Portuguese, Spanish, Russian, Chinese, Japanese
Dimensions 435 x 170 x 195 mm



Colour Scales



Title Scale Path Length Scale Range Scale Resolution Applicable Standard Add to quotation cart
ASBC Colour 10 mm 1.2 - 10.6 (extendable) 0.1 unit ASBC
Series 52 1 - 50 mm 4 - 30 1 unit
EBC 25 mm 0 - 27 (extedable) 0.1 units EBC Analytika
CIE L* a* b 1 mm - 50 mm dependant on spectral locus 0.01 ASTM E308
Transmission % 1 mm - 50 mm 0 % - 100 % 0.01 %
Optical Density 1 mm - 50 mm 0 - 2.5 0.0001
Absorbance 1 mm - 50 mm 0 - 1 0.0001
Delta E* colour difference 1 mm - 50 mm dependant on spectral locus 0.01
xyY chromaticity co-ordinates 1 mm - 50 mm 0 - 1 (x,y), 0 - 100 (Y) 0.0001 (x,y), 0.01 (Y) ASTM E308
XYZ Tristimulus 1 mm - 50 mm 0 - 100 0.01 ASTM E308



Delivery Content

  • PFXi Series Instrument
  • External Power Supply
  • Set of 3 Power Leads (UK, European and United States)
  • USB and LAN Cable
  • Quick Start Guide
  • USB Memory Stick (Containing Manuals)
  • RCMSi Starter Pack*
  • Certificate of Conformity
  • Accessory Box with 5 Volt Halogen Lamp, Conformance Filter, 1 x W600/OG/10 Cell, 1 x W600/OG/25 Cell
